Recasting a line from a Joe Green poem that will hopefully find its way on press soon. I originally cast this on a free weekend about a year ago, but job work took over and the poem was tucked away on a quiet galley. Now that the weather has cooled and nights have become chilly, the poem “House Warming” has been on my mind. Time to ink up! Today I found that the word spacing was a little tight on one of the lines – about a year ago I was excited to learn a trick which allows single position Linotype display mats to run on a duplex display mold. Must have been more focused on the trick than on the word spacing. So, fixed!
Recent project at the C.C. Stern Type Foundry: Run mats out of the magazine, proof and inventory, clean mats, clean magazine. This proof is of Excelsior 11 ^ 120. We’re short on the lower case “r.” There are only 2. That will be a problem. Hopefully they’re hiding out in a sorts drawer somewhere. Also, after going through about a pig’s worth of metal while casting this, the slug consistently was rough on the right side. This problem persists even after having replaced the mouthpiece and sawing out the throat. The mouthpiece heater is probably on its last legs. For now, I’ll add em spaces to avoid the edge of the slug, but will certainly have to revisit this issue in the future.
Metromedium No 2 (14^198, 14^186) - has been on my mind. I’ve been having fun casting and printing it. It is bold yet holds a distinct grace and plays well with ink. It prints nicely. And at 14pt, it’s an smooth runner on the machine. Initially I found the appearance of the figures “5” “0” to be a little striking (see pic) - I had suspected that sorts belonging to another version of the typeface had errantly found their way into the magazine. But no, the font number was confirmed and matched. I think it’s a nice feature - the lighter stroke of these figures add a “pulse” to surrounding text which teases the eye along the page. I’m also happy that this particular font includes the “special No 1” cap W, which was not the standard cap "W" redesigned for "Metro No. 2." As I understand, the "special No 1" sorts reflect Dwiggins’ original Metro drawings. (However, a third version of the cap "W" was also offered as an option as indicated in the Linotype's "Big Red" spec book, so don't quote me on that) More info about the evolution of Metro can be found in this excellent article by Paul Shaw. Anyway, the mats are in good shape, the sidewalls are sound and I’m tickled to cast and print from them. Here’s another example of the typeface used in recent piece set in all caps.
The broadside / poster pictured was printed to promote an upcoming film screening and panel discussion sponsored by the C.C. Stern Type Foundry. Foundry volunteers cast the type used on the poster, Jeff Shay cast that gorgeous cutting of Garamond (48pt, 24pt, 18pt) on his Ludlow at Buzzworm Studios (after proofing these slugs, I went down a Robert Hunter Middleton internet rabbit hole - to be explored later. Hopefully Jeff will be my guide, because it looks like I could get lost real fast. Amazing stuff there…), Rebecca Gilbert cast decorative ornaments on the monotype sorts caster at the C.C. Stern Type Foundry, and I cast the above mentioned Metromedium No 2 and smaller sizes of Garamond using the Linotype at Stumptown Printers. Rebecca then masterfully handled the press work at Stumptown Printers. The poster was a good excuse for a collaborative hot-metal project. Nice work, team!
If you’re in Portland, please come to the event.
Pressing On: The Letterpress Film
Tuesday, September 19th
Clinton Street Theater
2522 SE Clinton Street
Portland, OR 97202
Linotype Alumilite Magazines Shall not be trusted. This is the second one that has failed on me. No fun. The brass bottom magazines are quite heavy to haul around, but those suckers are solid. I haven't experienced this issue with the heavier magazines.
It’s an honor to have 3 fiddleink prints included in “Type Tells Tales” a recent book by Steven Heller and Gail Anderson. Drawing from early twentieth century to the present, this book documents selected work which explores non-conventional ways in which typography can convey a story. From the book’s intro: “A common theme is that type and letters are not passive, but are active participants in an entire composition” and “…our book is about well-meaning heretics who challenged and continue to bust standards.” Indeed. From the futurist letterpress print work of Fortunato Depero and Filippo Tommaso Marinetti, to the “analog” experimental offset lithography work of Walasse Ting and Robert Massin, to modern practitioners who meld digital techniques with traditional tools, there’s a lot in this book to be inspired by. I’m happy that my Linotype machine composed prints found a place among the pages. Thanks again to Abigail Steinem (Head Researcher), Steven Heller & Gail Anderson for the opportunity.
Today I cast a couple secret slugs to hide among the Linotype type order that I occasionally fulfill for a trade shop here in town. I’m not sure how they’ll take it: The Linotype operator owes the customer a beer? The customer owes the linotype operator a beer? The linotype operator is buzzed on beer? Hooray for beer? Who knows. I only hope that the press operator checks the slugs before printing. Secret Slug cast in Linotype 10^696 first and second position.
July 3rd! It’s Linotype Machine anniversary day! Today marks 131 years of a distinct kind of music. The sound of solid slug of type sliding onto a steel galley followed by the sound of brass matrices rhythmically chiming as they fall back into place within the Linotype magazine. The persistent “whirl” of the distributor screw and the assembler chute belt, sounding a call for action. It’s a fabulous symphony, even when the machine sounds come to an abrupt halt, and gruff curses from the operator can be heard. It’s all a part of the wonder. Thanks to Steve Cole and the Baltimore Museum of Industry crew for rallying and spreading the word about the anniversary today. And cheers to all who are acting as the custodians of these amazing machines - keeping them happy and running for future generations to experience. Keep the cams rolling and the metal flowing!
We're slowly making some room for the new magazines and racks. I'm standing in the space where a single bank type cabinet once stood. It's about the same foot print as one magazine rack. Need to make room for 5 more. Nice to see the machine from this perspective before the space gets filled up again!
I've been practicing mitering Linotype border using the Hammond glider saw. I almost took out a window here at Stumptown Printers when the miter vise clamp wasn't tight enough and a slug got away from me. Won't make that mistake again.
Looking pretty clean so far. This type form will be used for a limited edition keepsake broadside celebrating 11 years of the Stumptown Printers' Arigato Pak.
This is a great little video of a Russian made (?) line casting machine. Thanks to Bill Spurling for passing on the link. Check out the safety guard that flips into place over the mold and vise before casting.
I noticed a slight little build up of type metal on the pump plunger rod when I started casting this evening, and after a couple hours of casting lines this is what that build up became:
Linomite! It was enough to restrict the plunger from returning to its fullest upward position. Gotta keep an eye on this next time. I'm guessing that this happened because the pot was a bit too cool. I'll test the theory next time we cast. Otherwise, anyone out there have tips on how to prevent this?
This is a set of space bands lovingly tied up by an operator of the Stumptown Printer's model 31 long before we owned the machine. It's an example of marlinspike seamanship by an old Linotype salt. I hadn't had the heart (or need) to disrupt this tidy knot before today, but we needed the bands and so this is the documentation of the touch of a craftsman from years ago. We brought the bands to the C.C. Stern Type Foundry to use with the machine there. I believe that the old salt would approve.
I managed to get a couple lines off of the machine today, but printing, die cutting, hand bindery and prepress took the lion's share of shop time. I don't like to fire up the machine unless we have at least a handful if slugs to cast. Next time...
Got it! The properly justified slug
Resilient Mold Cam Adjustment
Consulting with the teachers
This illustration is a useful reference if you are in the back of the machine and cycling it by hand, and you need to know when to stop cycling(!) By looking at this cam, you can determine when the first elevator is resting on the vise cap, or when the justifications take place, etc. This illustration is scanned from the Intertype Book of Instruction, page 46.
